| Place of Origin: | China |
|---|---|
| Brand Name: | OEM |
| Certification: | CE，SGS |
| Model Number: | R3B11 |
| Minimum Order Quantity: | 500 square meters |
| Price: | USD 8.99 sqm |
| Packaging Details: | Customized Box |
| Delivery Time: | 12-18 work days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 200000 sqm per month |
| Thickness: | 2.0mm，2.5mm | Electrical Resistance: | EC 2.5X 10^4~10^6，SD 1.0*10^6~10^9 |
|---|---|---|---|
| Wear Group: | T | Application: | Electronic Plant,Medical Plant |
| Size: | 2mx20m | Material: | PVC |
| Feature: | Permanent Conduction | Function: | Anti Static /Conductive Or Dissipative |
| High Light: | R3B11 2.5mm Anti Static Vinyl Flooring,R3B11 Medical Plant Anti Static Vinyl Flooring,R3B11 2.0mm anti static vinyl tiles |
||
Conductive Flooring in Roll Very High Quality Permanent Conduction
ESD roll come as an economical solution because of their long-term life and therefore they are good in high-traffic and industrial areas such
as hospitals, schools, libraries, supermarkets, warehouses and so on.
Permanent antistatic floor uses the PVC resin as the main component, and utilizes the plastic particle interfaces to form the permanent
antistatic network. make the floor looks like the marble,have a good decorative effect. Widely used in telecommunication electronics ,computer
room,,clean room...etc
| Technical Data | ||
| DISCRIPTION | UNIT | |
| Type of flooring | Homogeneous PVC flooring | |
| Thickness | mm | 2.0~3.0 |
| Weight | g/m2 | 3200 |
| Width | mm | 2 |
| Length | mm | 15~20 |
| Fire resistance | B1 | |
| Electrical resistance | kv | ≤2 |
| Slip resistance dry | ≥0.3 | |
| Slip resistance wet | R9 | |
| PERFORMANCES | ||
| Abrasion group | P | |
| Abrasion resistance | mm | ≤0.10 |
| Castor wheel test | Suitable | |
| Residual indentation | mm | ≤0.04 |
| Color fastness | ≥6 | |
| Thermal resistance | m2k/w | ≈0.01 |
| Dimensional stability | % | ≤0.10 |
| Chemical products resistance | Very good | |
| Toxic testing | Suitable | |
| Tolerance for width and length | mm | ±0.15 |
| Residual indentation | mm | ≤0.15mm |
| Dimensional change on heating | % | ≤0.20 |
| abrasion wear | g/cm2 | ≤0.020 |
| Voltage | |V|<100V | |
| Decay time | <2S | |
| Electric properties | conductive | <1.0×106Ω |
| dissipative | 1.0×106Ω~1.0×109Ω |
Because Refine Union floor is impermeable, the surface dirty is easy to clean.
Avoid sharp scratches on the floor by hard object ,and maintain a smooth surface.
Clearing the floor by neutral detergent ,dry after washing,then coated with anti-static wax.
